Por LILYGO
LILYGO T-Keyboard T-Deck ESP32-S3 Development Board with White Keyboard 2.8 Inch Touch Screen LoRa Options
$76.09 - $87.98
Impuesto incluido.
Los gastos de envío se calculan en la pantalla de pago.
Precio habitual
$87.47
Precio habitual
Precio de oferta
$87.47
Precio unitario
por
No se pudo cargar la disponibilidad de retiro
Availability:
2000 en stock
SKU:
93523
Collections:
Precio habitual
$87.47
Precio habitual
Precio de oferta
$87.47
Details of T-Deck:
MCU: ESP32-S3FN16R8 Dual-core LX7 Microprocessor
* Wireless communication: 2.4GHz Wi-Fi & Bluetooth 5 (LE)
* Development environment: For Ar-duino, PlatformIO-IDE and Micropython
* Flash: 16MB; PSRAM: 8MB; Battery detection PIN: IO04
* Onboard functions: trackball, microphone, and speaker
2.8-Inch ST7789 SPI Interface IPS LCD
* Resolution: 320x240
* HD IPS color screen with full viewing angle
SX1262 LoRa Transceiver (Optional Chip)
* Transmit power: +22dBm
* Optional frequency: 433Mhz/868Mhz/915Mhz
Product Code:
Package Contents (Depending on Selected LoRa Version):
868MHz Version:
* 1 x T-Deck LORA-89 SX1262
* 1 x Pin Header (6-pin)
* 1 x Battery Cable
* 1 x 868MHz FPC Antenna
915MHz Version:
* 1 x T-Deck LORA-89 SX1262
* 1 x Pin Header (6-pin)
* 1 x Battery Cable
* 1 x 915MHz FPC Antenna
433MHz Version:
* 1 x T-Deck LORA-45 SX1262
* 1 x Pin Header (6-pin)
* 1 x Battery Cable
* 1 x 433MHz FPC Antenna
Without LoRa:
* 1 x T-Deck
* 1 x Pin Header (6-pin)
* 1 x Battery Cable
Packaging Details:
* Weight: 0.5kg
Note:
* Battery is not included.
* Other items pictured below are not included, for demonstration purposes only. Thank you for your understanding!
