Hand Radio Antenna Short Wave Radio Rod Base Station HF UV Small Whip Receive Transmitter

Hand Radio Antenna Short Wave Radio Rod Base Station HF UV Small Whip Receive Transmitter

Features:

- High-performance portable all-band antenna with detachable whip

- Continuous tune Rx from 0.6 to 460Mhz

- Continuous Tx from 3.5-460Mhz

- Engineered for the 817, 703, K1, K2 and Others

- 30-40dB gain on HF Rx over a plain whip

- Exclusive auto-transformer turning-unique, effective

- Detachable and convenient full-band whip antenna

- Receiving frequency: 0.6-450 megahertz continuous adjustment

- Transmission frequency: 3.5-460 MHz continuous adjustment

- Power: 25W PEP, 10W CW AM FM

- Designed for 817, 703, K1, K2 and other low power stations

- Short-wave receive gain 30- 40dB over normal whip antenna

- Unique and effective coil adjustment

- Shortwave listening enthusiasts - listening to HAM band signals

- It can greatly reduce noise and improve listening performance.

- It can be connected to other sizes of levers or long wires

 (recommended 7.6 meters soft wire) or very short dipole antennas.

Specifications:

- Box size: 10x5x2cm

- Whip Length: 170cm

- Net Weight: 220g

- Power: 20W

- BAND: UV, HF

- Version: 20160606

- 1.5mm Aluminum alloy shell

- 304 Stainless steel telescopic rod

- Antenna

- Model: 170Q9

- Carrying Length: 233mm

- Spread Length: 1710mm

- Segments Number: 9

- First Diameter: 2mm Solid Rod

- Max Diameter: 9mm

- Weight: 63.5 g

- Telescopic Part: 304 stainless steel

- Radio Frequency Connector: BNC/Q9 BRASS PLATING

Note:

Install & Remove The Rod Antenna.

When using the adapter, please use appropriate force to avoid excessive force damage.

When the tie rods are closed, do please retract it from the bottom section by section.

Do not push hard from the top to avoid the unevenness of the force, which may cause the tie rods to bend or even break.

Package Includes:

1 x Antenna

1 x Main Unit
