PA2 Speaker Management System Loudspeaker Management System Audio Processor 2 Input 6 Output for DBX
Description:
PA2 enables loudspeaker systems to optimize sound quality at a fast speed and in an accurate way. It offers many additional system tuning and sound optimization features, including compression, graphics and 8-band parametric equalizer, sub-harmonic synthesis, enhanced low-frequency response, built-in speaker crossover (for full-range, 2- and 3-way systems), limiting, and speaker timing adjustment and delay.
It supports wireless connection of mobile APP, IPA, and computer software.
Official software makes connection and use easier. You can use a mobile device or laptop computer to control it over the Internet from devices for Android, IOS, Mac and Windows.
Specifications:
ANALOG INPUTS:
- Number of Inputs: 1 RTA mic input and 2 line inputs
- Type: Electronically balanced/RF filtered and XLR female
- Impedance: > 40kΩ
- Max Input Level: > +20dBu
- CMRR: > 45 dB
- RTA Mic Preamp Phantom Power: +15 VDC
- RTA mic equivalent input noise: < -110dBu, 22Hz, -22kHz, 150Ω
ANALOG OUTPUTS:
- Number of Outputs: 6 line outputs
- Type: Electronically balanced/RF filtered and XLR male
- Impedance: 120 Ω
- Max Output Level: +20dBu
A/D PERFORMANCE:
- A/D Converter: IV conversion for dbx Type
- A/D Dynamic Range: 110dB A-weighted; 107dB unweighted
- Type IV Dynamic Range: 123dB with transient signal, A-weighted, 22kHz BW; 121dB with transient signal, unweighted, 22kHz BW; 115dB typical with program signal, A-weighted, 22kHz BW
- Sample Rate: 48 kHz
A/D Characteristics:
- Dynamic Range: 112 dB A-weighted; 110 dB unweighted
SYSTEM PERFORMANCE:
- Dynamic Range: ＞110dB unweighted; ＞107dB A-weighted
- THD+Noise: 0.002%, +4dBu, 1kHz, 0dB input gain
- Frequency Response: 20Hz-20kHz, ±0.5dB
- Inter-channel Crosstalk: < -110dB, -120dB typical
- Input to output crosstalk: < -100dB
- Delay: 10ms per output channel (60ms in total)
Package Included:
- 1 x Main Unit
- 1 x Instructions
- 1 x Power Cable
