RF Power Amplifier 1090MHz 38dB Lower Noise Amplifier for ADS-B RF Front-End

RF Power Amplifier 1090MHz 38dB Lower Noise Amplifier for ADS-B RF Front-End

Description:
Its RF front end is carefully designed with a two-stage low noise amplifier and a two-stage dedicated filter. It can be used for RF amplification of the front end of ADS-B receiver, featuring high gain, low noise and large dynamic range. Its dual filter structure ensures sufficient suppression of the out-of-band signal and effectively improves the signal-to-noise ratio.

Technical Parameters:
- Working Voltage: 3.3-5.0V DC
- Working Frequency: 1090MHz (Designed for ADS-B Receiver)
- Amplification Gain: 38dB
- Out-of-Band Rejection: -75dB@+-50MHz; -55dB@+-1GHz
- Connector: SMA-Female Port

Package Included:
- 1 x RF Power Amplifier
