M5Stack ESP32CAM ESP32 Camera Module Development Board OV2640 Camera Type-C Grove Port

Description:

The ESP32CAM is a tiny module based on ESP32 chip and OV2640. You can even program the ESP32CAM through the ESP-IDF by installing the ESP32 Core.

The ESP32CAM equips the ESP32 with everything necessary to program, run and develop on the wonderchip. It also features a LiPo charger (IP5306) , so your ESP32CAM project can be battery-powered (battery is not included) and truly wireless. Additionally, the board reserved the MPU6050,BME280 and an analog MIC.

Features:
◆ ESP32 specifications
    - Dual-core Tensilica LX6 microprocessor
    - Up to 240MHz clock frequency
    - 520kB internal SRAM
    - 4MB Flash memory
    - Integrated 802.11 BGN WiFi transceiver
    - Integrated dual-mode Bluetooth (classic and BLE)
    - Hardware accelerated encryption (AES, SHA2, ECC, RSA-4096)
◆ CP2104 USB TTL
◆ OV2640 sensor

   - Output Formats(8-bit):
     YUV(422/420)/YCbCr422
     RGB565/555
     8-bit compressed data
     8-/10-bit Raw RGB data
   - Maximum Image Transfer Rate:
     UXGA/SXGA: 15fps
    SVGA: 30fps
    CIF: 60fps
  - Scan Mode: Progressive
◆ Camera specifications
    - CCD size : 1/4inch
    - Field of View : 78 degree
    - Maxmium Pixel: 200W
◆ Sensor best resolution: 1600 * 1200
◆ Dimension: 25mm x 24mm
◆ Weight: 5g


Package Included:
- 1 x M5Stack ESP32 Camera Module

Note:
1. When the development environment is IDF, the reference code is as follows:
https://github.com/m5stack/esp32-cam-demo
2. There are pads on the board for MPU6050 and bme280. They can be soldered by yourselves.
3. Onboard IP5306 can be connected to lithium battery. Battery is not included in this package.
