Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $211.32 | $207.00 | $200.54 | $191.91 | Contact US |
Description:
- GM70CK is specially designed to monitor relevant parameters and fault of air compressor driven by diesel engine and gas engine. It is equipped with standard can communication port and built-in J1939 protocol. Relevant parameters can be read through CAN port of engine ECU. The backlight can be changed to white or black as you want.
Parameters Display | Protection |
Engine RPM | Over speed |
Engine oil pressure | Under speed |
Engine water temperature | Low oil pressure |
Engine oil temperature | High water temperature |
Engine fuel level | High oil temperature |
Engine battery voltage | Low oil level |
ECU related parameters | Low water level alarm |
Air Compressor related parameters(Special feature for GM70CK) | External instant alarm |
4 switches input status display | Low coolant level switch warning |
Output status display of 3 relays | Sensor Open |
Cumulative number of startups | Maintenance expire |
Total number of alarms | ECU alarm failure |
Total Crank times | ECU communication Failure |
Current running time | External shutdown alarm |
Total running time | |
Maintenance notice |
SPECIFICATION OF GM70C | |
Power supply | DC 8~36 V |
Consumption power | Standby:24V:MAX1W |
Working:24V:MAX3W | |
MAX Accumulating Time | 99999.9Hours(Min Store time:6min) |
Programmable Relay output 1 | Max 5 Amp DC+VE Supply voltage |
Programmable Relay output 2 | 250V/5 AMP Non-contact normally Open/Closed output |
Programmable Relay output 3 | |
Switch value input | Available if connecting with Battery |
Working condition | -25-65℃ |
Storage condition | -40-85℃ |
Protection Level | IP54:when water proof rubber gasket is added between meter and its panel |
Insulation strength | Apply AC 1.5 kV voltage between high voltage terminal Insulation strength and low voltage terminal; The leakage current is not more than 3mA within 1min. |
Overall dimension | 175mm*128mm*39mm |
Panel cutout | 152mm*112mm |
Weight | 0.5Kg |
