Tags: H.264 HD Encoder
Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $194.37 | $190.41 | $184.46 | $176.52 | Contact US |
Description:
- Mine Tech HD WIFI Encoder (wifi hdmi encoder) is our newest professional HD audio & video digital display encoder with powerful functionality.It supports H.264 wifi encoding,dual Streaming data.
- This iptv streaming wifi encoder is equipped with 1 HDMI channels input supporting MPEG4 AVC/H.264.
- High Profile code format & main Profile code format.Its high integration and cost effective design make this device widely used in variety of digital distribution systems such as CATV digital head-end.Satellite and terrestrial digital TV etc.,also it supports VLC decode.
Applications:
1.IPTV encoder
2.Digital Signal
3.Video Conference
4.Replace HD Video Card
5.Hotel TV system
6.Live Broadcast
7.Teaching/Campus Broadcast
8.Recording System
9.NVR(Net Video Recorder)
Features:
- Support H.264 Baseline Profile/H.264 Main Profile/H.264 High Profile wifi hdmi encoder
- Support MJPEG/JPEG Baseline
- Audio coding support MPEG1 Audio Layer2
- CBR/VBR/ABR code rate controlling, 16kbit/s-40Mbit/s
- Support Network interface full-duplex mode 1000M
- Support 1 channel HDMI input,also supports converting HDMI to VGA input
- Support up to 720P,1080P HD video input
- Support image parameter settings
- Support HDCP protocol and HD blue-ray
- Support https UTP RTSP RTMP ONVIF protocol
- The WEB operating interface,configuration interface in Chinese and English are optional.
- Authority management for WEB operating interface.
- Support the double stream output
- The main stream and the second stream can be transferred by different networking protocol
- Support the setting for stream resolution.
- Supports MP3 and AAC audio format selection
- Support switching mono and stereo for audio output stream.
- Support GOP frame rate settings
- Support a click to restore the default configuration
- Support decoding the set-top box
- Low-power design
- 3U high-grade chassis,with main power automatic switching function,which ensure the stability of the system
Specifications:
Input:
- Video:1 channel HDMI input (version 1.3a) support HDCP
- Resolution:1920×1080_60i/60P,1920×1080_50i,1280×720_60p;1280×720_50p
- Encoding:H.264/AVC High Profile Level 4.0(HD)
- Code-rate:0.8Mbps~12Mbps
- Code-rate controling:CBR/VBR
- GOP type:adjustable
- Video Advanced Pretreatment:De-interlacing,Noise Reduction,Sharpening
Audio:
- Encoding format:AAC,MP3
- Sampling rate:Adaptive and output sampling rate is optional
- Bit-rate:32K,44.1K,48K,4K,96K,128K,160K,192K
- Sampling accuracy:24 bit
- Code-rate:64Kb/s~384Kb/s
System:
- RJ45:1000M
- Program stream:https,UTP,RTSP,RTMP,ONVIF protocol
- Confirguration interface:WEB operation interface
- Upgrading:Can be upgrated by internet
Miscellaneous:
- Dimension (WxLXH):170*130*30mm
- 3U standard chassis:3U structure,A 3 u chassis support 16 channel coding plate
- Approx weight:Single 0.5KG,3U 8KG
- Temperature:0~45 (work),-20~80 (storage)
- Power:Single chassis: 12V/DC,3U chassis: AC 220V±10%, 50/60Hz
- Consumption:5W/one channel,3U chassis 80W
Package List:
- 1 x H.264 HD Encoder
