STM8S Development Board Core Minimum System Board STM8S105K4T6 with Code Routines

STM8S Development Board Core Minimum System Board STM8S105K4T6 with Code Routines

Description:
Each piece of the core board factory test procedures are pre- programmed , even after power LED will blink , and in order to detect the core board is working correctly.

Technical Information:
- Core board schematics (PDF format ) x 1
- Provided separately in the IAR and STVD two development environmentsRegister OperationThe two sets of matching I / O port routines, routines timers , UART transmit routine , UART receive routine , clock switching patients , AD routines.
- ProvidedRespectively in the IAR and STVD two development environmentsLibrary functions operateOf2 sets of matching I / O port routines, timer routine , UART transmit routine , UART receive routine , clock switching patients , AD routines.

STM8S_MiniKit_32 core board main features :
1: Use STM8S105K4T6 for control IC
2 : leads all pins , mark out the next pin pins, pin welded
3 : Support SWIM debug mode
4: USB MINI line to take power, or 2.54 pin to take power

Product details:
1.SWIM -board interface , user-friendly debugging.Onboard reset button, the user LED, power indicator.
2.Pin default is not weldingUsers can according to their needs , welded to the side or underside .
3.OnboardUSB poweredCan be used directly to the computer USB port power supply . We have also added a new version5V power supply interface. You can use an external 5V input can also be used in the case of USB-powered , the external output 5V!
4.Factory chip production to ensure quantities , advanced technology to ensure product quality ! Pin spacing on both sides is an integer multiple of 2.54 , you can easily useBreadboard or hole board to extend the experiment!
5.You can use our ST LINK V2 to simulate , debug , programming the STM8 minimum system .

STM8 Series Features:
- Speeds of up to 30MIPSHigh-performance core;
- Strong anti- interference abilitySafe and reliable quality ;
- Leading 130 -nanometer manufacturing process , excellent value for money ;
- Program space from 4K to 128K, chip select from 20 feet to 80 feet, and a wide range of products;
- Low system cost , embedded EEPROM and high precision RC oscillator ;
- Development easyWith local tool support ;

Packing List :
- Core board x 1
