UNI-T UPO2204 200MHz 2GSa/s 4-Channel Oscilloscope Ultra Phosphor Oscilloscope with 8" Touchscreen

UNI-T UPO2204 200MHz 2GSa/s 4-Channel Oscilloscope Ultra Phosphor Oscilloscope with 8" Touchscreen

Features:
* Analog channel bandwidth: 200MHz
* Analog channel real-time sampling rate: 2GSa/s
* 2 or 4 analog channels selectable, each with standard 56Mpts memory depth
* Maximum waveform acquisition rate: 1,000,000wfms/s
* Supports Bode plot loop test and analysis functions
* Hardware real-time waveform recording and analysis up to 120,000 frames, with support for USB storage device export
* Waveform math functions: addition, subtraction, multiplication, division, digital filtering, logic operations, and advanced math
* 4M-point enhanced FFT, supporting frequency setting, waterfall display, detection settings, and marker measurement
* Automatic measurement of 36 waveform parameters
* Supports parameter measurement during scanning
* Multi-Scopes supports independent triggering and fluorescent display for multiple channels
* Multi-channel independent 7-digit hardware frequency counter
* DVM supports multi-channel independent AC/DC true RMS measurement
* Rich triggering functions: edge, pulse width, video, slope, under/overshoot pulse, delay, timeout, duration, setup/hold, Nth edge, and pattern trigger
* Practical zone trigger function for capturing sporadic signals and observing complex signals
* Protocol trigger and decoding function (optional): RS232, I²C, SPI, CAN, CAN-FD, LIN, FlexRay
* Ultra Phosphor 2.0 display technology with 256-level grayscale
* 8-inch 800×480 HD capacitive touchscreen supporting gestures: tap, swipe, zoom, edit, drag, etc.
* Rich peripheral interfaces: USB Host, USB Device, LAN, EXT Trig, AUX Out (Trig Out/Pass/Fail), VGA
* Supports SCPI programmable instrument standard commands
* Supports WEB access and control
* Wide range of applications: Applicable fields include communications, semiconductors, computers, integrated circuit design, instrumentation, industrial electronics, consumer electronics, automotive electronics, field maintenance, research and development, and education.

Packing List:
* 1 x UPO2204 Main Unit
* 4 x 200MHz Probes (Including Accessories)
* 1 x Power Cable
* 1 x Data Cable
* 1 x Calibration Certificate
* 1 x Download Guide
* 1 x Certificate of Conformity

Packaging Details:
* Weight: 5kg

Note:
* Please obtain the product's upper-computer software and electronic manual according to the download guide, or contact customer service. Thank you!
