UNI-T UTP1310 320W 32V 10A 4-Digit DC Power Supply Regulated Power Supply for Mobile Phone Repair
Description:
UTP1310 is a high-quality, highly stable economic DC regulated power supply featuring a 4-digit LED display for voltage and current. It includes protection functions such as over-voltage protection (OVP), over-current protection (OCP), and over-temperature protection (OTP), with OVP/OCP values adjustable according to user requirements. Its exceptional stability and reliability make it an ideal tool for use in universities, corporate production lines, and home appliance repair workshops.
Features:
* Rated Output Voltage: 0–32V
* Rated Output Current: 0–10A
* Setting Resolution: 10mV/1mA
* 4-Digit High-Precision Voltage/Current Display
* Over-voltage and Over-current Protection
* Key Lock
* 3 Sets of Stored/Recallable Settings
* Independent Output Switch
* Encoder Adjustment
Specifications:
* Rated Output Voltage: 0–32V
* Rated Output Current: 0–10A
* LED Display Digits: 4
* Output Power: 320W
* Load Regulation:
** Voltage: ≤ 0.1% + 5mV
** Current: ≤ 0.2% + 3mA
* Power Supply Regulation:
** Voltage: ≤ 0.01% + 5mV
** Current: ≤ 0.2% + 3mA
* Setting Resolution: 10mV/1mA
* Setting Accuracy:
** Voltage: ≤ 0.1% + 1 digit
** Current: ≤ 0.2% + 3mA
* Ripple:
** Voltage: 10mVrms
** Current: 5mArms
* Operating Voltage: AC 110V/220V ±10%, 50Hz/60Hz
* Dimensions (W × H × D): 80mm × 150mm × 230mm
* Weight: 2.5kg
Packing List:
* 1 x Set of DC Power Supply
Packaging Details:
* Weight: 3kg
