X9-MOVTADHS 8" HD CCTV Tester IP Camera Tester Monitor 4K Resolution AHD CVI TVI SDI Full Function

X9-MOVTADHS 8" HD CCTV Tester IP Camera Tester Monitor 4K Resolution AHD CVI TVI SDI Full Function

X9-MOVTADHS:
- M *: Digital Multimeter: DC and AC voltage, Resistance measurement, Continuity test, Diode measurements, Capacitance measurement
- O *: Optical power meter, Wavelength: 1625, 1550nm, 1490nm, 1310nm, 1300nm, 850nm, measuring range, -70 ~ + 10 dBm, for optical power testing and Fiber link loss relative measurement
- V *: Visual fault locator: 10mW visual fault locator with 650nm wavelength can emit red laser sources to test multi-mode and single mode fiber's bending and breakage, test range 10KM
- T *: TDR cable test: BNC cable, network cable, telephone cable, RVV cable and lift cable, cat 5/6 cable length and short circuit. Measuring range 1.2 KM
- ADHS *: 8MP TVI, 8MP CVI, 5MP AHD, HD SDI / EX-SDI test

IP Camera Tester Functions:
* 8-inch 2048x1536 IPS high-definition 2K full-view retina capacitive touch screen with higher brightness and smoother and clearer camera image display. (NEW)
* Dual Gigabit Ethernet ports, 10/100 / 1000M adaptive. Real-time detection of network video bandwidth, backbone network traffic monitoring, etc. (NEW)
* Intelligent fast charging technology, it can be fully charged in about 3.5 hours, realizing charging for 10 minutes, construction for half an hour, and better increase work efficiency. (NEW)
* Analog high-definition level comprehensive test, hardware high-speed sampling and processing technology, accurate measurement of video peak-to-peak value, synchronization level and burst level, one-button test report generation, integrated coaxial high-definition, analog video, one-button link, one-button output Illustration. (NEW)
* New hardware decoding, supporting H.265 decoding. Under the H.265/H.264 encoding mode, the resolution of the main stream test image is up to 4K. (NEW)
*  New testing tool for Hikvision support batch activation, batch IP modification, user name and password modification, new custom channel name modification, three font sizes can be adjusted at will, and camera time can be customized to display position, which is more convenient. Restore factory settings, etc. (NEW)
*  The new test tool for Dahua supports for batch activation of Dahua cameras, batch modification of IP addresses, reservation of mobile phone numbers for password retrieval, new custom modification of channel names, and modification of user name, password and other parameters. (NEW)
*  Multi-channel preview, up to 16 cameras can be previewed at the same time, and one-button link to onvif to play images. (NEW)
*  Advanced link monitoring, supporting Ethernet statistics, error frame statistics, frame length statistics, network port loopback tests, etc. (NEW)
*  12V power test. It can measure the voltage, current and power of a camera power supply. Monitor the working status of a 12V power supply to the camera in real time, generate a test report with one click, and save the test value. (NEW)
*  Support HD-SDI/EX-SDI/3G-SDI camera image test. Support camera, video, zoom, playback.
*  Enhanced version of IP discovery, faster and more accurate! Blind test of the IP address of unknown IP camera in seconds.
*  Speedy ONVIF generates a camera test report with one button, including camera IP address, resolution, encoding and other related information. Supports cross-network segment testing; supports audio and video synchronization testing; one-click activation for Haikang cameras and IP modification and more. (NEW)
*  Support for IPC private protocol testing of more than 80 network camera manufacturers such as Dahua, Haikang, ACTi, Samsung.
*  Support network PTZ control function (ONVIF), swipe up, down, left, right, etc. to control PTZ rotation.
*  PoE DC48V power output, maximum power 25.5W.
*  12V 3A DC power output.

Other Functions:
*   BNC attenuation test. Hardware high-speed sampling processing technology tests the coaxial cable attenuation value in real time. Plug and play, reference table comparison. (NEW)
*  Enhanced line hunter, new appearance, indicator light + knob-type volume adjustment key, stronger sense of technology; digital + analog two modes, new digital mode, stronger anti-interference ability rejects noise and enables more accurate line hunting. (NEW)
*  Support HDMI high-definition digital signal input, the highest resolution can reach 1080P. Support video, photo and playback. It also supports HDMI signal output, the highest resolution is 4K. It can output the current screen display content, and the output resolution can be switched between 4K / 1080P / 720. (NEW)
*  Network cable TDR test. Test the parameters such as the state, length, attenuation, reflectivity, impedance, and delay deviation of network cables. (NEW)
*  Test the voltage and power of PoE switches and PoE cameras. Test the voltage and power of DC12V power input and DC12V output of the instrument. (NEW)
*  Backlight button has better quality feel. The keyboard is still clearly visible in darkness. (NEW)
*  New light-shielding plate, no fear of strong light. The screen is clearly displayed under strong light. (NEW)
*  Screen projection function. Support mobile phone or PC projection. You can install mobile phone screen projection APP, real-time receiving CCTV tester screen pictures. Or supports for VLC player at PC end, enabling monitor installers to share information.
*  Built-in WIFI function. Can test wireless network cameras, supporting the creation of WIFI hotspots.
*  Support CVBS loop test, the instrument loop sends and receives CVBS color bar signals, and quickly tests BNC cables.
*  New system. You can install mobile or tablet mobile client software running by IPC manufacturers by yourself. And it fits for QQ, WeChat or other applications in APK format.
*  Support screenshot function. Press and hold the confirmation key to take a screenshot, which is used to save various test reports or quickly take a screenshot of the camera.
*  Video camera and video record function. Support naming in Chinese for easy file lookup.
*  Support playback of 4K high-definition video recording files and movie media files such as MP4.
*  Analog video image display, PTZ control, image zoom, camera, video, playback and other functions.
*  Original video level measurement function. Measure the peak-to-peak, sync level, and burst level of analog video signals.
*  Network test functions such as PoE voltage measurement, PING, IP address scanning, and port flicker.
*  Enhanced network cable test. Test network cable and telephone line sequencing and continuity. The test box has a special number which needs to be customized. You can search for the end of a thread.
*  5V 2A power output can be used as a mobile phone charger.
*  Audio input and output functions.
*  Working time up to 13 hours.

Package Included:
- 1 x Set of CCTV Tester
