XYZ 3 Axis Linear Stage Trimming Platform Bearing Tuning Sliding Table 60x60mm

Tags: Sliding Table

Availability: In stock, usually dispatched in 1 business day

  • Price:$106.57
  • Price in reward points: 1066 Reward Points: 11
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $104.44 $102.31 $99.11 $94.85 Contact US
Quantity:

XYZ 3 Axis Linear Stage Trimming Platform Bearing Tuning Sliding Table 60x60mm



Specification:
- Move direction:XYZ axis three degree of freedom
- Material:Aluminum
- The slider size:60mm x 60mm
- Stroke:XY axis ±6.5mm,Z axis 10mm
- Load: 29.4N (3kgf)
- Rail Type:V-type rail
- Minimum scale: 0.01mm
- Accuracy:0.01mm
- Net Weight:0.7kg

Features:
- It uses cross roller guide can achieve high precision,smooth movement.
- The main material for aluminum.Micrometer head driving.
- For precision movement,precise positioning, stable performance,easy installation and removal.

Applications:
1.DVD,MD,CD-related disc reading lens and writable optical head production and testing equipment.Mainly arcuate positioning platform.
2.LCD projector prism positioning and loading.
3.The optical fiber positioning,optical communication system products and testing equipment.
4.LCD production and testing equipment.
5.The semiconductor related production.equipment and testing equipment Evaluation.

Package Included:
- 1 x XYZ 3-Axis Platform
