Black 450W Charger Board Intelligent High Power Fast Charging Module with 6 Charging Port for Desktop or Car
Specification:
- Power supply: 12 - 24VDC
- Maximum power: 450W
- Output port: 4 x Type-C ports, 2 x USB ports
- Output power: 450W max (100W + 100W + 65W + 65W + 65W + 65W)
- C1 - C2 output: 5V3A 9V3A 12V3A 15V3A 20V5A (max 100W)
- C3 - C4 - USB1 - USB2 output: 5V3A 9V3A 12V3A 15V3A 20V 3.2A (Max 65W)
- Support PD input
- Size: 95 x 75 x 27mm
- Simultaneous multi channel fast charging: 6
Description:
- This is a brand new desk charging product that can meet most charging needs, with a total of 6 outputs and a total power of 450W.
- There are 4 type-c ports and 2 USB ports in the 6 ports. Two out of the four C ports are for voltage up and down output, that is, when 12V is input, the two C ports on the left can also output up to 20V5A. So, except for the two ports on the left, the other four ports require 24V to achieve maximum output power.
- C1-C2 has a maximum output of 100W20V5A, and C3, C4, USB1, and USB2 have a maximum output of 65W. It is recommended to use a 24V power supply to achieve maximum power for the product. The LM5175+SW2303 scheme is used for the voltage reduction and pressure reduction of these two channels, with each channel having four 5C670L for MOS tubes providing lower heating. The remaining four channels are the SW3526 voltage reduction solution.
Features:
- The center of the top panel of the product is a switch indicator light, and the lights on each interface are fast charging indicator lights. When the output voltage is higher than 5V, they will light up, making it convenient to indicate the fast charging status of each circuit.
- The bottom CNC aluminum board contacts the circuit board through thermal conductive silicone, quickly dissipating the heat of the original component and reducing the temperature during long-term operation.
- Support multiple fast charging protocols
Note:
- The input port of the product is a DC5.5x2.5mm circular socket, and the power supply needs to be matched with the socket to function properly.
Package Included:
- 1 x Fast Charging Module
