China-Made PCAN2 PCAN-USB Adapter Compatible with Original IPEH-002022/002021 & for INCA Cummins
Description:
The PCAN-USB adapter enables a simple connection to CAN networks. Its compact plastic casing makes it suitable for mobile applications. The opto-decoupled version ensures galvanic isolation of up to 1500 volts between the PC and the CAN side.
The package also includes the PCAN-View CAN monitor for Windows® and the PCAN-Basic programming interface.
The device driver supports multiple operating systems, allowing the program to easily access the connected CAN bus.
Technical Specifications:
* Supports USB connection (full-speed mode, compatible with USB 1.1, USB 2.0, and USB 3.0)
* High-speed CAN connection (ISO 11898-2)
* Supports bit rate adjustment: 5Kbit/s ~ 1Mbit/s
* Time stamp resolution: about 42µs
* Compatible with CAN 2.0A (11-bit ID) and 2.0B (29-bit ID)
* CAN bus connection via 9-pin D-Sub interface (compliant with CiA® 303-1)
* CAN electrical isolation up to 1500V
* For Windows 7, Windows 8.1, Windows 10, and Windows 11
* For Linux system. PCAN driver (Socket CAN) is integrated into the kernel for Linux
* For macOS (MacCAN)
Packing List:
* 1 x PCAN-USB Adapter
Packaging Details:
* Weight: 0.4kg
