CUAV X7 Pro CORE Drone Autopilot Flight Controller For FPV Drones Quadcopter Industrial Drones

Availability: In stock, usually dispatched in 1 business day

  • Price:$1,080.00
  • Price in reward points: 10800 Reward Points: 108
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $1,058.40 $1,036.80 $1,004.40 $961.20 Contact US
Quantity:

CUAV X7 Pro CORE Drone Autopilot Flight Controller For FPV Drones Quadcopter Industrial Drones

Series Introduction:

The core unit of the CORE series flight control unit contains all the functions of the flight control unit. Users can design their own flight control carrier board according to the interface definition of the core unit, or purchase our CAN PDB products for use.

Attention:
- Core series products do not contain the flight control board. Buyers need to buy a flight control board or use our CAN PDB.
- Please contact sales to obtain the interface definition of Core before purchasing.

X7 Pro Autopilot:
X7 Pro is an advanced autopilot independently designed by CUAV. It uses a higher-performance STM32H7 processor and integrates industrial-grade sensors and ultra-low temperature drift sensors. Compared with the previous flight controller,it has better performance and more reliability. This board can run firmware for ArduPilot perfectly. X7 Pro is ideal for industrial drones.

X7 Pro Compatibility List:
- For Ardupilot firmware: AC4.03/AP4.05/AR4.01 Firmware version and later
- For Ardupilot Supported Models: Copter/Plane/Helicopter/VTOL/unmanned vehicle/Rover, etc. Complete models supported for Ardupilot
- For PX4 firmware: Incompatible (wait for the NUTTX underlying upgrade)
- For PX4 supported models: Incompatible

Features:
- CORE built-in shock absorption design: Using reliable CUAV patented flight control shock absorption system
- Faster than ever: X7 series autopilot use STM32H7 series processors, CPU operating frequency increased to 480Mhz, storage 1024K, FLASH 2048K, has a faster processor and larger storage, and uses 512K EEPROM, can expand waypoints to 2048. Bring more imagination to flight applications
- Adapt to harsh environment: The X7 series autopilot adopts a large number of car-level chips and has a built-in high-precision sensor temperature compensation system, which makes the sensor work at a constant temperature to ensure that the sensor can operate with high accuracy and high sensitivity in high and low temperature environments
- Always stable: Series sensors for Inven sense+Bosch+ADI+TE are used, which have lower noise and stronger anti-shock and vibration performance. With the industrial-grade compass RM3100, the flight stability and anti-interference performance have brought a qualitative improvement
- Simply upgrade your V5+: The X7 and X7 Pro autopilot adopts a modular design, which can be customized based on the drone structure, and is fully compatible with the V5+ Core autopilot interface. As simple as changing the CPU
- CUAV Quality: CUAV deeply cooperated with the team for APM & PX4 to complete the hardware design and software adaptation of the CUAV X7 series, and was produced and tested by the CUAV smart factory. Each autopilot was used for independent I/O through the CUAV AATS system connectivity and sensor stability test to ensure the stability and reliability of the autopilot

Package Included:
- 1 x Autopilot Flight Controller

Note:
- Other items mentioned are not included in the package, for demonstration purposes only. Thank you for your understanding!
