• LCD Display GSM980 GSM 3G 65dBi Mobile Phone Signal Amplifier Booster Repeater 2000 Square Meter Amp

LCD Display GSM980 GSM 3G 65dBi Mobile Phone Signal Amplifier Booster Repeater 2000 Square Meter Amp

Availability: In stock, usually dispatched in 1 business day

  • Price:$81.32
  • Price in reward points: 813 Reward Points: 8
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $79.69 $78.07 $75.63 $72.37 Contact US
Quantity:

LCD Display GSM980 GSM 3G 65dBi Mobile Phone Signal Amplifier Booster Repeater 2000 Square Meter Amp

Description:

- A mobile phone signal repeater provides the ultimate solution in any area where Cellular communications can not work well due to leak of signals,the repeater Device features easy installation & operation ,build-in indoor antenna and no Interferece,it could also improve indoor electromagnetism environments.
- Protract cellular battery life and reduce radiation of cellphones.
- A mobile phone repeater is ideal for house ,home,office use.

Features:
- Enhance mobile phone signal strength.
- Improve communication quality.
- Reduce cellphone radiation.
- Protract cellular battery life.
- Economic building life.
- Easy installation.
- Build-in power supply.
- High gain ,easy installation and operation.
- Full-duplex,singal-port design,build-in power supply.
- Use ALC technology ,adjust extent automatically.
- LED light working &signal condition indicators.
- Big linear power,control intermodulation & scatteration stably.
- Dependability stand by GB6993-86 standard.
- Compatibility of electromagnetism according with ETS300 609-4.

Display device (for reference):
- The external power supply detecting normal display OK.
- Internal power supply detecting normail display OK.
- MMIC circuit detects normal display OK.
- 50dbm signal input and detection to achieve full displayed.

Specifications:
- Frequency Range:
  Up Link: 1920MHz--1990MHz; Donw Link:2110MHz--2180MHz
  Up Link: 890MHz--915MHz; Donw Link:935MHz--960MHz
- Output Power: 30DBM ±3dBm
- Gain: Up Link: 65Db ±10db; Donw Link:70Db ±10db
- Impedance: 50Ω
- Power Supply: AC 110/220V (used AC/DC Adapter 12V dc)
- Seclusion: >65dB
- Compact Design: Indoor Use
- Item Diemension: 240MM*182MM*22MM
- Connect Mode: N connector
- Ambient temperature: -10°C~60 deg C

Signal coverage area :
1.Support Maximum coverage area is 2000 square meters.( Depend on the area condition)
2.One indoor antenna only use for about 300 square meters.
If want to make all use of 2000 square meters which the host supports,need to add more indoor antennas (about6-7) and power divider / splitter.

Package listing:
- 1 x GSM-980 LCD display signal repeater
- 1 x Power adapter
- 1 x Manual
- Cables
