Mini Open source Tau Labs 10dof Sparky Flight Controller CC3D upgraded version CAN input for DIY FPV drones 250 260 320 400

Availability: In stock, usually dispatched in 1 business day

  • Price:$86.70
  • Price in reward points: 867 Reward Points: 9
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $84.97 $83.23 $80.63 $77.16 Contact US
Quantity:

Mini Open source Tau Labs 10dof Sparky Flight Controller CC3D upgraded version CAN input for DIY FPV drones 250 260 320 400

Description:

- The latest Black Edition, you can choose to accept 3.3v or 5v power supply
- The latest development of flight control, very small, only about 3X3cm
- CC3D upgraded version, upgrade M4 processor with floating point arithmetic
- 9-axis sensor, integrated electronic compass, gyroscope, accelerometer, a barometer
- PPM SBUS DSMX signal input, can not be directly input PWM
- Increased input CAN bus protocol to facilitate the development of different modules
- Supports a variety of GPS functions, fixed, fixed high and home
- The main modes are multi-axis mode and fixed-wing mode
- There android phone ground stations, support for mobile control! Develop powerful

Specifications:
- GPS capable for functions such as RTH (Return To Home), Position Hold and Waypoint navigation in conjunction with a ground station.
- Mavlink compatible for the use of telemetry radios for use with a ground station to provide location information and waypoint navigation.
- Barometric pressure sensor on board for accurate altitude hold indoors or out
- 9 dof accelerometer / gyro for the absolute quickest and most accurate angle recognition and correction
- 2 serial ports
- PPM only - SBus Support and DSM2/x support with user selectable 3.3v or 5v setting.
- Camera stabilization output for 3 axis
- 10 channel outputs
- Up to 3 adc inputs for rssi
- Very compact design, perfect for small UAV's where space is limited. Also excellent in larger machines as well.
- Weight 6.9g with right angle header pins
- 30mm x 30mm mounting pattern
- Available with 90 degree header pins and straight header pins for easy installation no matter what your frame requires.

Package Included
-1x Tau Labs 10DOF Sparky Flight Controller CC3D
