TeSeek Aluminum Alloy Heavy-duty L-Shaped Mount 180X250MM Astronomical Gimbal Bracket for Telescopes and Equatorial Mounts

Introduction:
- Aluminum alloy CNC processing, size of 180*250mm, thickness of 14mm, vertical plate with wide dovetail, vertical plate strip slot suitable for the standard spacing of 35mm M8 screw holes, can adjust the center of gravity position up and down, can also be installed through wide dovetail, also support the installation of narrow plates on the vertical plate; On the horizontal plate, there are mainly multiple M8 screw holes spaced 35mm apart, with a middle M8 through-hole spaced 35mm apart.
- It can be installed normally on the latitude and longitude platform, or on equatorial mounts with latitude and longitude modes. At the same time, it can be installed on equatorial mounts with latitude and longitude modes by reversing the horizontal plate, and telescopes can be installed. The main purpose is to install various binoculars, such as astronomical binoculars within the 100 caliber of SKY ROVER and various monocular telescopes. Self weight: 1KG.

Package Included:
- 1 x L Mount
