Coaxial Bias Tee 10MHz-6GHz 2A 50V Broadband Radio Frequency Microwave Coaxial Bias Tee

Coaxial Bias Tee 10MHz-6GHz 2A 50V Broadband Radio Frequency Microwave Coaxial Bias Tee

Description:
In the receiving system, the receiver is usually away from the receiving antenna, and the two are connected by a longer coaxial cable. The longer the cable is, the greater the loss is. When the sensitivity of the system needs to be improved, the antenna output is generally connected to the low noise amplifier for line compensation. Some receivers do not have the ability to coaxially feed the antenna. This product is for you to achieve this function.

Specifications:
- Working Frequency: 10MHz-6GHz
- Insertion Loss: 0.3dB@550MHz
- Max. Operating Voltage: 50V
- Max. Working Current: 2A
- Connector: SMA-K
- Impedance: 50Ω
- Size: 35 x 22 x 10mm

Package Included:
- 1 x Bias Tee
