iFlight Morgoth Quadcopter Frame FPV Frame 210mm 5 Inch FPV Racing Drone Frame Kit Unassembled

iFlight Morgoth Quadcopter Frame FPV Frame 210mm 5 Inch FPV Racing Drone Frame Kit Unassembled

Features:
- Mirror painting and polishing process, five-axis CNC machining shell mold.
- The use of high-temperature prepreg and a 150-degree high-temperature one-time molding process with hollow inside line (same as the carbon fiber board frame material) gives it high-gloss mirror surface and high strength and light weight of the carbon fiber board frame.
- Motor cable is threaded internally, so that installed frame does not have messy wiring.
- Chassis uses five-axis CNC to make molds and five-axis cutting and processing lens holes and three-holes. 45-degree flight angle five-axis cutting heat dissipation holes ensure that airflow cools the equipment, and overall streamline design makes the frame accelerate faster.

Parameters:
- Frame name: Morgoth
- Frame type: long X type
- Wheelbase: 214mm
- Overall frame size: 148.5*154.5mm
- Camera size: 14mm nano
- Weight: 68.5g
- Motor hole size: 16*16mm
- Motor center hole size: Diameter 6.5mm
- Electrical equipment size: 20*20mm-diameter 3mm / 30.5*30.5mm-diameter 3mm
- Overall thickness of bottom plate: 6-7mm

Package Included:
- 1 x Set of Drone Frame

Note:
- Assembling is needed.
- Optional Colors: Blue, Black, Pink. Please choose the color you want when purchasing.
