RMP-B45 45KG Dual Shaft Brushless Servo PWM Digital Servo High Torque Servo for Models Robotic Arms

RMP-B45 45KG Dual Shaft Brushless Servo PWM Digital Servo High Torque Servo for Models Robotic Arms

Features:
- Digital servo with high torque
- Suitable for model aeroplanes, car models, ship models, robots, robotic arms, etc.
- Compatible with various servo controller boards
- CAD drawings and a variety of MCU control programs can be provided
- All-metal output shaft: 25T metal precision output gears with long life and high torque. Outer diameter 6mm and inner diameter 3mm
- All-metal housing is impact resistant, enabling fast heat dissipation. Aviation alloy material makes the shape more cool
- Multiple angles (90°, 180°, 270° and 360°) to adapt to more working environments
- Brushless motor greatly extends the life of the servo

Product Parameters:
- PWM protocol
- Locked-rotor and over-temperature protection
- Stall torque: 45Kg-cm (7.4V)
- No-load speed: 0.098s at 60 degrees (7.4V)
- All-metal gears
- Resolution: 4096 steps
- Motor type: brushless motor
- Effective angle: 360°
- 7075 aluminum alloy 8-hole servo horn
- PH2.0 silicone wire 20cm
- Size: 40x40x20mm
- Weight: 81g

Package Included:
- 1 x Set of Digital Servo
