Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $45.77 | $44.83 | $43.43 | $41.56 | Contact US |
100V 10A and 100V 20A optional,please specify when you place order
if you need 200V 10A/200V 20A.please contact us for price
Specifications:
- DC power supply port:5.5mmx2.5mm
- Power supply voltage:12V-15V 10W (receommend over 13V)
- min power consumption: 12V 0.36w /15V 0.6W when heatsink not work
- Max power comsumption:12V/5W 15V/8W
Load power | |
Rated power | 180w |
Max power | 200w max |
protection temperature | ≥80℃ |
measure range | (2V/10A)(2.8V/20A) |
Rated voltage | 0-100V(optional)0-200V(optional) |
Rated curent | 0-10A (optional)0-20A (optional) |
Rated power | 0-200W |
Resistance | 100V(0.1-1000Ω)200V(0.1-2000Ω) |
Precison | rated voltage | rated current | Rated power | Resistance |
Resolution | 10mV | 1mA | 10mW | 100mΩ |
accuracy | 0.02%±5 | 0.02%±5 | 0.02%±6 | 0.02%±1 |
Resolution | 10mV | 1mA | 10mW | 100mΩ |
Precision | 0.2%±2 | 0.5%±5 | 0.5%±6 | 5%±1 |
communication protocal | Modbus-Rtu |
Port | RS485 |
Add | 1 |
rate | 9600bps |
.. | 128 |
