Wecon PI3043IE 4.3-Inch HMI Human Machine Interface with 4-Core Processor 128MB Flash + 64MB RAM

Wecon PI3043IE 4.3-Inch HMI Human Machine Interface with 4-Core Processor 128MB Flash + 64MB RAM

Features:
* Mainboard Specifications: Quad-core high-performance processor with 128MB Flash and 64MB RAM memory
* Display: 4.3-inch, resolution: 480×272
* Interface: COM1: RS232, RS422/RS485
* Download Method: Data cable download + USB flash drive download

Specifications:
* CPU: Quad-core high-performance processor
* Touch Screen: Resistive

Display:
* Display Size: 4.3-inch
* Resolution: 480×272
* LCD Brightness: 300cd/m²
* Backlight Type: LED
* Backlight Life (Half-life): Greater than 20,000 hours

* Storage:
* Flash: 128MB
* Memory (RAM): 64MB
* SD Card Slot: None

I/O Interface:
* USB: Micro-USB: USB 2.0 × 1 (can be powered via USB, used for image and project downloading)
* Serial Interface: One serial port (7-pin terminal). RS232, RS422/RS485 (combined)
* Ethernet: None
* CAN: None
* HDMI-Compatible Interface: None

Perpetual Calendar:
* Built-in

Power Supply:
* Input Power: 24V DC (12–28V DC)
* Power Consumption: Less than 5W
* Power Isolation: None

Other Parameters:
* Enclosure Material: Engineering Plastic PC+ABS (Flame Retardant Grade)
* Dimensions: 142.0mm × 86.0mm × 30.3mm
* Cutout Dimensions: 131.0mm × 78.0mm
* Weight: 0.19kg

Operating Environment:
* Protection Rating: Front panel compliant with IP65
* Storage Temperature: -20℃ to 70℃
* Operating Temperature: -10℃ to 55℃
* Operating Humidity: 10% to 90% RH (non-condensing)
* Vibration Resistance: 10-25Hz, 2G for 30 minutes along X, Y, and Z axes

More Information:
* CE Certification: Complies with CE standards
* Software: PI Studio Configuration Software
* Remote Control: Not supported

Packing List:
* 1 × HMI Display

Packaging Details:
* Weight: 0.6kg
