ZXB-380S 380kg High Torque Servo Digital Servo for Robot Mechanical Arm
Features:
- 380kg.cm high torque
- Three Control Ways: Serial bus control/PWM control/Potentiometer control
- 2 Switchable Modes: It can be switched between servo mode and motor mode to meet your various needs
- Position Feedback: Real-time feedback of its current position
- Settable Angle: Its maximum control angle is up to 355°. Default angle modes are 355° and 180°
- Easy Control: Easy to operate with communications protocol and communication instruction provided.
- Convenient Expansion: Serial bus communications way enable one cable to connect to multiple bus devices.
- Magnetic Encoder: Non-contact encoder features high precision, long life span, wide controlled angles, 12-bit resolution
Specifications:
- Operating Temperature: -15℃ to 70℃
- Working Voltage: Rated 24V (12 to 24V)
- Quiescent Current: 15mA
- No-load Speed: 0.5s/60° (380kg)
- No-load Current: 113mA
- Stall Current: 10.08A (380kg)
- Stall Torque: 380kg.cm
- Control Signal: TTL Serial Signal
- Protocol Type: Single Wire Serial Port/Half Duplex
- ID Range: 0 to 255
- Communications Rate: 9600bps to 1000000bps
- Rotation Angle: Max. 355°. Default modes 180° and 355°
- Feedback: Position
- Resolution of Position Sensor: Max. Angle 355°/4096
Package Included:
- 1 x 380kg.cm Digital Servo
