X820 V3.0 SATA Storage Expansion Board with Power Adapter Metal Shell Support 4TB for Raspberry Pi

X820 V3.0 SATA Storage Expansion Board with Power Adapter Metal Shell Support 4TB for Raspberry Pi

Description:
No driver required, can provide stable power supply for Raspberry Pi, can be connected to PC or MAC for data transmission, on-board power switch, can install system, flexible power supply.

Features:
-Support up to 4TB 2.5-inch SATA interface mechanical hard drive or solid state drive.
-Support hard disk system installation and startup.
-Onboard power touch switch, press to start, press for 2 seconds to turn off the power.
-Flexible power supply, X820 can power the Raspberry Pi motherboard, and the Raspberry Pi motherboard can also power the X820.
-Onboard USB power output port and XH2.54 power output connector, power to the motherboard via 40-pin header or Micro-USB socket.
-Super high-speed USB 3.0 to SATA 6.0Gb/s bridge controller.
-USB3.0 super high speed connection to PC or MAC for data transmission.
-USB2.0 high-speed connection with Raspberry Pi for data transmission.
-No driver required, fully compatible with Raspberry Pi.
-Ideal storage expansion board for Raspberry Pi.
-Onboard external power switch connector, convenient for you to create a personality shell.
-Easy to assemble by yourself.

For Raspberry Pi Motherboard Version:
for Raspberry Pi 1 Model B+/ 2 Model B / 3 Model B / 3 Model B+.

Power Requirements:
5V DC +/- 5% 4A

Product Details and Installation Tutorial:
http://www.suptronics.com/miniPCkits/x820_v3.0.html

Packing List:
-1 x X820 V3.0 Expansion Board
-1 x USB Data Cable 60cm
-1 x USB Port Connection Board
-1 x USB2.0 A-Male to Micro B Power Cable
-1 x XH2.54 2P Power Cable 10cm
-4 x M2.5*12mm Copper Pillar
-8 x M2.5*6mm Screw
-4 x M3*15mm Copper Pillar
-6 x M3*6mm Screw
-1 x Power Adapter 5.1V 4A
-1 x Metal Shell

Note: Not include Raspberry Pi motherboard.
